The Ninghai Bamboo Tower stands 20.3 m tall in Ninghai County, Zhejiang, China. It has six stories plus a roof-access attic, a 130 m2 footprint, and about 800 m2 of total floor area. Completed in 2024, the building is described by its design team as the world's first tall engineered mass-bamboo building, a claim tied to its height and multi-story design.
Image Credit: frantic00/Shutterstock.com
The project followed nearly 20 years of research by the authoring team on bamboo materials and structures. It was designed to assess the constructability of engineered mass bamboo for tall buildings and show what the material can deliver once it leaves the laboratory bench. The completed tower also provides a working platform for studying vibration, durability, thermal behavior, and acoustics.1
With a focus on the Ninghai bamboo building, this article explores the design of mass-bamboo buildings, their carbon footprints, bottlenecks to further deployment, and potential future uses.
How Does the Skeleton Carry a Load?
Load paths in the tower are separated by direction. Engineered mass bamboo frames carry gravity loads through glulam sub-beams and I-shaped joists, which support two types of floors: one constructed from cross-laminated bamboo and timber panels, and the other made from flame-retardant veneer boards.
Framed lightweight timber or bamboo shear walls resist lateral forces along the longer axis, while braced bamboo frames manage forces along the narrower axis.1
The design was primarily influenced by wind, ensuring that the maximum story drift remained within the 1/350 limit under code-required load combinations. Analysis was performed in SAP2000, with member design following timber design methods and experimental data.
Download a free copy of this page here!
Selected components passed static and dynamic non-destructive evaluation, and the measured elastic modulus exceeded the design value. Construction involved raising repeating two-story modules using frame-and-platform sequences adapted from traditional wood-building practices.1
The Material Behind the Frame
Engineered bamboo is divided into two families with distinct production logics. Laminated products slice culms into narrow strips, plane them, remove nodes, dry them to a controlled moisture content, and bond them in parallel or crossed layers.
In contrast, scrimber crushes whole culms into connected fiber bundles, soaks the bundles in resin, aligns them lengthwise, and hot-presses them under high pressure, using close to 80% of each culm.2
Performance characteristics differentiate these two families and influence material selection. Scrimber achieves a density of 950 to 1300 kg/m3 and delivers consistent strength suited to demanding structural work, whereas laminated bamboo has a density between 600 and 850 kg/m3 and is vulnerable to interlaminar failure due to poor bond-line adhesion.
Cross-lamination narrowed the directional strength ratio in one reported study from 8.32 to 1.52.2
Published data on engineered bamboo exhibits significant variability in the technical literature, a pattern that complicates routine design decisions. Across 31 separate studies, the modulus of elasticity ranged from 0.58 to 32.3 GPa, with an average of 10.8 GPa. Modulus of rupture ranged from 31.3 to 174.4 MPa, while thin-strip and thick-strip glulam recorded 101.1 and 104.9 MPa in bending.2
Joints Decide Seismic Behavior
Connections also contribute to the structural risk in mass bamboo frames, which is why they receive considerable research attention. A review published in Sustainable Structures examines the damage modes, strength, ductility, and energy dissipation capacity of steel-to-engineered-bamboo beam-column joints under cyclic loading.
Given that bamboo and timber share broadly similar properties, existing joint types developed for wood structures can be transferred to bamboo structures with adapted detailing.3
Joint response shapes whole-structure seismic performance, since member material and connection form together set elastic behavior under load reversals. Steel-to-engineered-timber connections exhibit good seismic performance, a finding that supports the selection of steel braces for the Ninghai frame.
Cyclic testing programs, combined with numerical simulation, remain the evidence base that gives such details a defensible place in tall designs.3
Carbon Accounting from Plantation to Panel
A cradle-to-gate assessment of 15 mm bamboo scrimber flooring at a density near 1100 kg/m3 reported a total footprint of 3.11 kg of CO2/m2, with 1.45 kg of that arising during manufacturing. Steam use for drying and carbonization accounted for most of that share, and adhesive made up close to 10% of the oven-dry bamboo mass.4
A four-year-old Moso bamboo stand in an Italian field study held 14.8 megagrams of carbon per hectare in aboveground biomass, 8.4 megagrams belowground, and 40.7 megagrams in the upper 30 cm of soil, slightly higher than the 33.2 megagrams measured under adjacent cropland. Culms held 80% of that aboveground biomass, and since individual culms live for seven to 10 years, this allows repeated harvest cycles.5
Culms harvested and directed into furniture and building materials extend carbon storage for several decades, placing long-lived structures such as the Ninghai Bamboo Tower at the productive end of the whole chain. Processing energy, therefore, largely determines the practical climate margin for mass bamboo in China, where plants now meet domestic construction demand and supply a large export market for panels.5
Standards, Cost, and Market Entry
Certification limits commercial uptake in this sector as firmly as mechanics does. Emerging bio-based products that fall outside accreditation schemes rarely meet specifications because clients
question their compliance with fire-resistance regulations.
Creating a fresh standard for a single new material can cost around £200,000, while testing against a suitable existing standard reduces accreditation cost by roughly an order of magnitude.6
Cost evidence from built bio-based projects points in two directions at once. Initial client construction costs for bio-based materials were 10–25% higher than a conventional steel build, an increase tied partly to design work and the material itself.
Running costs fell sharply after handover, however, with one bio-based building costing one-third less to operate than a concrete building standing on the same site.6
Life cycle assessment rules add further friction for specifiers and manufacturers. EN 15804 covers both incineration and landfill while omitting composting, and it treats land transformation inconsistently, which weakens direct comparisons against conventional construction products. Durability testing against insect and rodent infestation and against fungal decay remains a standing requirement for every newly developed bio-based material entering the construction market.6
What the Tower Sets Up Next
Ninghai provides this emerging field with a full-scale, code-compliant physical reference for engineered mass-bamboo construction. Structural analysis indicated that the design met the wind and seismic requirements, while continued monitoring will provide further evaluation of the building’s performance.
Its value will continue to grow as the research team publishes vibration, durability, thermal, and acoustic results, as these datasets feed the grading rules and fire-performance documentation essential for advancing bio-based high-rise construction.1
References and Further Reading
- Xiao, Y. et al. (2025). DESIGN, CONSTRUCTION AND INSTRUMENTATION OF A SIX-STORY ENGINEERED MASS BAMBOO BUILDING. World Conference on Timber Engineering. DOI:10.52202/080513-0068. https://www.proceedings.com/content/080/080513-0068open.pdf.
- Jafarnia, N., & Mofidi, A. (2025). Engineered Bamboo for Sustainable Construction: A Systematic Review of Characterization Methods. Sustainability, 17(13). DOI:10.3390/su17135977. https://www.mdpi.com/2071-1050/17/13/5977.
- Liu, Y. et al. (2024). Progress on the connection performance of steel-engineered bamboo beam-column connections under cyclic loads: a review. Sustainable Structures. DOI:10.54113/j.sust.2024.000037. http://www.sustain-dpl.com/UploadFile/article/202405312226316935.pdf.
- Huang, H. et al. (2025). Life Cycle Carbon Footprint Assessment of a Typical Bamboo-Based Fiber Composite Material. Fibers, 13(10). DOI:10.3390/fib13100134. https://www.mdpi.com/2079-6439/13/10/134.
- Chiti, T. et al. (2024). Carbon sequestration in a bamboo plantation: a case study in a Mediterranean area. Journal of Forestry Research. 35(51). DOI:10.1007/s11676-024-01696-9. https://link.springer.com/article/10.1007/s11676-024-01696-9.
- Dams, B. et al. (2023). Upscaling bio-based construction: challenges and opportunities. Building Research & Information, 51(7), 764–782. DOI:10.1080/09613218.2023.2204414. https://www.tandfonline.com/doi/full/10.1080/09613218.2023.2204414.
